Electrically Conductive Deck Plate

DRY AREA | ANTI-STATIC

Introducing Crown's Electrically Conductive Deck Plate
Guard your components and equipment with Crown's Electrically Conductive Deck Plate, which rapidly neutralizes static charge. Our deck plate features a static dissipative surface that is ideal for industrial work environments. The deck plate's top surface enhances traction, while the PVC foam backing provides anti-fatigue relief for those who stand for long periods of time.

FEATURES

  • Resistivity of 10⁶ ohms per square
  • Beveled edges for improved safety
  • Stock mats include a ground cord, which can be connected to an electrical outlet. It is recommended to use one cord per 10 feet

APPLICATIONS

Provides a heavy-duty solution for dry areas - computer work station and terminals, sensitive electronic equipment areas, and electrical rooms.



More Information

  • Stock mats include one grounding cord.
  • It is recommended that there should be one grounding cord for every 10' of matting.
  • For custom cuts and full rolls the grounding cords must be purchased separately.
  • 75' Rolls are manufactured to a tolerance of ±1".
  • Full rolls are not beveled on ends - rolls with beveled ends are priced as custom cuts.

See Grounding Cords





Prop 65 WARNING: 65003

75

Anti-Fatigue

90

Durability

90

Traction

Additional Information

Sizes: 2' x 3', 3' x 5', 3' x 12'

Roll Sizes: 3' x 75'

Colors: Black

Pattern: Diamond

Thickness: 9/16"

Warranty: Total Confidence

Customization: Yes, up to 75'

Material: Extruded vinyl with a diamond deck plate top surface and PVC foam backing

Technical Data

Material: Extruded vinyl surface with PVC foam backing

Surface electrical properties: 1/100 sec from 20,000 volts to harmless

ELECTRICAL PROPERTIES: 10⁸ ohms (Ω) per ASTM D257 (Test Method ESD-S7.1_1994)


ABRASION RESISTANCE: < .5 gram loss per ASTM D4060 (Wheel (H38-2000 Rev)


BACKING-

AVERAGE DUROMETER: 40 per ASTM D2240 (Shore 00)


RESILIENCY: > 15% per ASTM D2632


AVERAGE DENSITY: 31 lbs/ft³ per ASTM D1667
